AN Male - AN O-ring (UNF) Male - Black aluminum

Here you will find AN nipple adapter for gasoline plants etc. These lightweight nipple adapters are of very high quality and have a really good throughput flow, which is why they are often used by the aerospace industry and other high-performance applications. Qualitec has many different types of nipple adapter for eg oil hoses, petrol hoses etc. They are typically stocked and shipped the same day as ordering.

All of our AN nipple adapter is made of aluminum, with an anodized / anodized multi-color surface treatment that is not only really neat, but also provides the aluminum with optimal corrosion protection.

Note

Nipple adapter is available with several types of threads, both metric and NPT and UNF, etc. we have nipple adapter with metric thread:
AN4 - M8 x1 - (M8 = 8.0 millimeters in external thread diameter - The last number is thread increment (millimeters) per lap).
or:
AN4 - AN4 O-ring (7/16 "x20 UNF) - (7/16" = 11.11 millimeter external thread) - the last number is the number of threads per inch (25,4mm).
You can calculate the outside diameter (7/16 x 25,4mm = 11,1125mm). possibly use a threaded table.

Mounting

This Nippel adapter has an O-ring on the straight cut thread, and can be screwed directly in, without the use of a second gasket, or aluminum washer.
